SKU #: FL-RGM.DUR.0105 MPN #: RGM.DUR.0105

Fluidyne 5 Row Extruded Tube Aluminum Radiator 01-05 GM 6.6L Duramax

Name: Fluidyne 5 Row Extruded Tube Aluminum Radiator 01-05 GM 6.6L Duramax
Brand: Fluidyne High Performance
Price: 1095.0 USD
Availability: InStock

$1,095.00

Get 1095 points in loyalty rewards

Fluidyne 5 Row Extruded Tube Aluminum Radiator 2001-2005 Chevy GMC 6.6L Duramax

Fluidyne Aluminum Radiator for 2001-2005 Chevy GMC 2500HD 3500HD 6.6L Duramax

Fluidyne 5 Row Duramax Radiator for 2001-2005 Chevy GMC 2500HD and 3500HD

Fluidyne Extruded Tube Aluminum Radiator 2001-2005 Chevy GMC Duramax Diesel Trucks

Description

Upgrade your Chevy/GMC 2500HD or 3500HD 6.6L Duramax with the Fluidyne 5 Row Extruded Tube Aluminum Radiator. Built for diesel trucks that tow, work, and run under heavy heat, this radiator is designed to deliver stronger cooling performance and long-term durability compared to standard aftermarket radiators. Fluidyne’s extruded aluminum core uses a strong single-piece tube design that helps eliminate common failure points found in folded and brazed radiator tubes. With race-proven cooling technology, thick aluminum construction, and a proprietary fin design for improved heat dissipation, this radiator is built to handle real diesel stress from daily driving to heavy towing and performance use. Designed as a direct-fit crossflow radiator for Chevy/GMC 2500HD and 3500HD models with the 6.6L Duramax, this aluminum radiator includes an integrated transmission cooler and ships in heavy-duty protective packaging to help ensure it arrives ready to install.

Free Customer Loyalty Program

No Salesmen, Just Enthusiasts

Upgrade your Chevy/GMC 2500HD or 3500HD 6.6L Duramax with the Fluidyne 5 Row Extruded Tube Aluminum Radiator. Built for diesel trucks that tow, work, and run under heavy heat, this radiator is designed to deliver stronger cooling performance and long-term durability compared to standard aftermarket radiators.

Fluidyne’s extruded aluminum core uses a strong single-piece tube design that helps eliminate common failure points found in folded and brazed radiator tubes. With race-proven cooling technology, thick aluminum construction, and a proprietary fin design for improved heat dissipation, this radiator is built to handle real diesel stress from daily driving to heavy towing and performance use.

Designed as a direct-fit crossflow radiator for Chevy/GMC 2500HD and 3500HD models with the 6.6L Duramax, this aluminum radiator includes an integrated transmission cooler and ships in heavy-duty protective packaging to help ensure it arrives ready to install.

Vehicle Fitment

2001-2005 Chevy/GMC 2500/3500 6.6L Duramax

WARNING: Cancer & Reproductive Harm - P65Warnings.ca.gov

FEATURES & BENEFITS:

Extruded aluminum core improves strength, heat transfer, and long-term durability
Race-proven Fluidyne cooling technology is built for demanding diesel truck use
5-row crossflow design helps manage heat during towing, hauling, and high-load driving
Proprietary fin design supports improved airflow and faster heat dissipation
Thick aluminum construction helps handle diesel vibration, pressure, and heat
Integrated transmission cooler provides added cooling support

SPECIFICATIONS:

Length: 45.16"
Height: 20.55"
Depth: 4.78"
Radiator Style: Crossflow
Core Length: 34"
Core Height: 20"
Core Depth: 2"
Radiator Inlet Size: 1.89"
Radiator Outlet Size: 1.89"
Inlet Location: Upper driver side
Outlet Location: Lower passenger side
Finish: Natural
Material: Aluminum
Rows: 5
Transmission Cooler: Yes
Transmission Cooler Adapter Fittings Included: No
Transmission Cooler Line Connection: None
Fan Included: No
Radiator Cap Included: No
